Type M 5 Foot Lengths
**Please note when ordering Type M that it is called and ordered by the Nominal I.D. Please refer to chart below. Example : An order of 1/2" M would yield .625-OD X .028 Wall X Length.
5 FT SECTIONS FOR GROUND SHIPPING (COST IS PER 5 FT SECTION)( +/- 10% cut tolerance)
Manufactured to spec ASTM B88 is the Standard Specification for Seamless Copper Tube , ANSI/NSF Standard 61 Drinking Water System Components.
All of the specifications require a minimum copper plus silver content of 99.9% and phosphorus content between .015 - .040%. As indicated by the
compositional requirements, the copper tube is essentially lead free.
NSF 61 , Alloy C12200
Called by the NOM ID size Type M is used for domestic water-, service and distribution-, fire protection-, solar-, fuel and oil-, HVAC-, compressed air-, oxygen-, LPG gas-, snow melting-, steam- and vacuum-systems. Copper tubes of Type M copper tubing are typically used with wrot copper fittings. ASTM specifications are B-88.
**Please note that the straight length hard temper copper tubing listed here is called and ordered by the Nominal , ID size. Please reference this size when ordering any copper fittings or plumbing tools.**
PSI of Soldered and Brazed Joints
Standard-Tube-Certificate-of-Conformance
Specifications Chart
Data Sheets-Type K,M,L&ACR
Data Sheets-DWV
Tubing Wall Thickness & Weights
-
3/4 Type M Hard Copper 5 FT Length
Original price $14.00 - Original price $14.00Original price $14.00$16.32$16.32 - $16.32Current price $16.32| /Original price $14.00 - Original price $14.00Original price $14.00$16.32$16.32 - $16.32Current price $16.32| / -
1 Type M Hard Copper 5 FT Length
Original price $21.00 - Original price $21.00Original price $21.00$24.48$24.48 - $24.48Current price $24.48| /The Copper manufactured to the chemical, mechanical, cleanness and eddy-current test requirements specified in ASTM B280 or ASTM B837.
Original price $21.00 - Original price $21.00Original price $21.00$24.48$24.48 - $24.48Current price $24.48| / -
1 1/4 Type M Hard Copper 5 FT Length
Original price $31.00 - Original price $31.00Original price $31.00$36.14$36.14 - $36.14Current price $36.14| /Original price $31.00 - Original price $31.00Original price $31.00$36.14$36.14 - $36.14Current price $36.14| / -
1 1/2 Type M Hard Copper 5 FT Length
Original price $43.00 - Original price $43.00Original price $43.00$50.13$50.13 - $50.13Current price $50.13| /;Standard Specification for Seamless Copper Tube and is measured and called by the Outside Diameters.
Original price $43.00 - Original price $43.00Original price $43.00$50.13$50.13 - $50.13Current price $50.13| / -
1/2 Type M Hard Copper 5 FT Length
Original price $11.04 - Original price $11.04Original price $11.04$12.86$12.86 - $12.86Current price $12.86| /Original price $11.04 - Original price $11.04Original price $11.04$12.86$12.86 - $12.86Current price $12.86| / -
2 Type M Hard Copper 5 FT Length
Original price $67.00 - Original price $67.00Original price $67.00$78.12$78.12 - $78.12Current price $78.12| /Original price $67.00 - Original price $67.00Original price $67.00$78.12$78.12 - $78.12Current price $78.12| / -
3 Type M Hard Copper 5 FT Length
Original price $130.00 - Original price $130.00Original price $130.00$151.58$151.58 - $151.58Current price $151.58| /All of the specifications require a minimum copper plus silver content of 99.9% and phosphorus content between .015 - .040%. As indicated by the co...
View full detailsOriginal price $130.00 - Original price $130.00Original price $130.00$151.58$151.58 - $151.58Current price $151.58| /
